Elevating power chair designed to raise you up to eye level while providing smooth ride performance, comfort, and everyday maneuverability.
Available at our Lakeland showroom. Call us to check availability, confirm current pricing, and arrange purchase.
Description
- HCPCS Code: K0830/K0831 Group 2 Standard, Seat Elevator
- 12" of power adjustable seat height
- Top speed of up to 3.71 mph, both in elevated and non-elevated positions
- 300 lbs. weight capacity
- 24.4" turning radius
- Active-Trac Suspension with Mid-Wheel 6 technology provides maximum stability in a variety of environments
- Battery range of up to 14.1 miles at 220 lbs. and 13 miles at 300 lbs.
- Non-scuffing, flat free tires (10" drive wheels, 6" caster wheels)
Documents: Brochure (PDF)
Additional information
| Brand | Pride Mobility |
|---|---|
| Condition | New |
| Weight Capacity | Light (Up to 300 lbs) |
| Weight capacity | 300 lbs. |
| Top Speed | Up to 3.71 mph |
| Ground Clearance | 0.98" at motor bracket |
| Turning Radius | 24.41" |
| Overall Size | Length: 41.54" Width: 23.25" |
| Drive Wheels | 10", Flat free |
| Caster Wheels | 6", Flat free |
| Suspension | Active-Trac with Mid-Wheel 6 Technology |
| Range | Up to 13 miles at 300 lbs. Up to 14.1 miles at 220 lbs. |
| Component Weights | Complete Assembly (without batteries): 197.2 lbs. Batteries: 22.2 lbs. (10.1 kg) each |
| Drivetrain | Two motor, Mid-Wheel 6 drive |
| Brakes | "Intelligent Braking" electronic regenerative, disc park brake |
| Batteries | Two 12-volt, sealed lead-acid, non-spillable deep-cycle U-1 batteries |
| Battery Charger | 5 amp, off -board |
| Freewheel Operational Force | Less than 60 N |
| Drive Control Operational Force | Less than 5 N |
| Maximum Rated Slope | 6° |
| Maximum Obstacle Climbing Ability (Ascending and Descending) | 1.57" |
